Plain Weave Discs Stainless Steel Filter Mesh For Pharmacy / Chemical Fibers
Stainless steel Wire Mesh AISI304 62/0.17mm x 1000mm For Filtration
| Specifications | U.S. | Metric |
|
Mesh Size |
62 per in |
62 per 25.4mm |
| Wire Diameter | 0.0067 in | 0.17 mm |
| Opening | 0.0094 in | 0.239 mm |
| Opening % | 34 % | 34 % |
| Weight / sq. ft | 0.01705 lb | 0.0077 kg |
Description
- Material: Stainless steel (aisi304, 316, 304L, 316L, 321).
-
Size: from 1000mm in width to 2000mm.
-
Weaving Type: Plain Weave.
- Material can be cut with tin snips, laser, or aircraft shears.
- Commonly used for air vents, and filters. This sturdy market grade mesh is woven from a standard wire diamete
- Extensive uses in processing of oils, chemicals, food, pharmaceuticals, also sorting and screening of solid, liquid and gas in mine, metallurgy, airspace, machine making, etc.
- Used for screening and filtering in the acid or alkaline environment, and used as a mud mesh in petroleum industry, as a screen mesh in chemical industry, and as a pickling mesh in electroplating industry.
- Plain weave woven wire cloth is used for the majority of wire cloth woven by Hebei DaShang Wire Mesh Products Company. Each warp wire crosses alternately above and below every weft wire and vice versa.
- Warp and weft wires are normally of the same diameter.
- Plain weaves are used for the majority of commercial applications and for filtration where a high flow rate is required.
FAQ
Q: Are you a manufacturer?
A: Yes,we have been in providing the professional products in this field for OVER 15 years.
Q: Do you have ISO & CE standard certificate ?
A: Yes, our all of wire products have pass CE Europe Certificate , click here for checking
Q: How many days will the samples be finished? And how about the mass production?
A: Generally,2 days for samples ,the time of mass production depends on the quantity,25 -30 days.
Most of our product are for export, well sold in the USA, Germany, Europe, Canada, Africa and other countries and regions. Our experienced staff can produce wire mesh processed products according to our customers’ demands.
